Design Concept:

• 0° to 90° tilt angle
• Heavy-duty cylinders
• Standard hand control for lowering / raising tilt
• Standard Features
• Standard upender capacities range from 3,000 to 100,000 pounds.
• Robust reinforced welded steel construction.
• Full steel bottom plate.

ZTRFM offers a comprehensive range of Hydraulic Upenders designed to meet a variety of industrial requirements. Our 90° Upenders are perfect for safely repositioning pallet loads as well as irregularly shaped items, such as rolls and coils. To enhance the handling of pallets, crates, or coils, conveyors and V-Cradles can be added to the platform for precise positioning.

Key Features:

• Efficient Coil Manipulation: Provides a quick and convenient solution for rotating coils.
• Heavy-Duty Brake System: A robust disc brake ensures the load remains stationary at any position.
• Reversing Magnetic Starter: Comes with a 115-volt pendant control for easy operation.
• Safety Features: Equipped with stop and over-travel limit switches for secure operation.

Additional Features:

• Customization Platforms: Larger platform sizes and higher load capacities are available upon request.
• V-Block Options: Standard or urethane-faced V-Blocks can be supplied to suit different applications.
• 180° Horizontal Rotation: The system allows for 180-degree rotation, enabling use from the same side.
• Forklift Accessibility: Includes pockets for forklift truck pickup for ease of transport.

Note: If the load is not a coil, please specify the load’s center of gravity for proper configuration.

Profile design of Upenders:

1. The Upender adopts automatic hydraulic system to take the coil to coil car, it is easy and safe way to transition from a horizontal to vertical (and back) orientation to load coil on the mandrel or cradle uncoiler. It is also powered from the hydraulic decoiler and controlled by coil loading car.

• Skidded Coil is Loaded onto Horizontal Platform
• The Platform is Rotated 90 degrees vertically onto loading car

Coil is Raised and Lowered to fed into the decoiler mandrel, align with decoiler mandrel (Skid is Removed)
