Description of Webslide Clip Roll Forming Machine

Webslide Clips Machine are specially designed for both exterior curtain walls and interior studs, allowing for adjustments to accommodate building structure deflection at the top of the wall. They also offer flexibility for situations requiring stand-off.

The WS 3.50 and WS 5.50 Deflection Clips provide various attachment options to the structure, tailored to the base material. This can be accomplished using power actuated fasteners, screws, concrete anchors, or welding, as specified by the engineer of record and outlined in the engineered shop drawings. When stand-off bridging is needed, it is advisable to include a steel stud to span the necessary distance.

Profile drawing:



ZTFRM Webslide Clip

The ZTFRM Webslide Clip is designed for use with exterior curtain wall steel studs, particularly in by-pass applications.

• It accommodates standoff situations as necessary.
• The clip allows for vertical movement of up to 2.50” (1.25” in each direction).
• Available in two sizes, it features 2 slots for 3 5/8” or 4” studs, and 3 slots for 6” or 8” studs.
• The design includes pre-punched holes to ensure accurate fastening locations.



Used with exterior curtain wall studs, specifically in by-pass applications：

Designed for use with exterior curtain wall studs, particularly in by-pass applications, the WSC 350 and WSC 550 Deflection Clips accommodate standoff situations as needed.

• These clips allow for up to 2.5″ of vertical movement, providing 1.25″ in each direction.
• They come in two sizes, featuring two slots for 3 5/8″ and 4″ studs, or three slots for 6″ and 8″ studs.
• Pre-punched holes are included to ensure accurate fastening locations.

Attachment to the structure can be accomplished using power actuated fasteners (PAF), screws, concrete anchors, or welding, depending on the base material and as specified by the engineer of record in the engineered shop drawings. If stand-off bridging is necessary, it is recommended to include an additional steel stud to span the required distance.

Webslide Clip Roll Forming Machine working flow:



The Technical Specifications Of Webslide Clip Rolling Forming Machine：

Webslide Clip rolling forming machine
1.Material of coil	Material Thickness	0.4-0.9mm galvanized sheet full hard 85-95, G550, PPGI
2.Forming system	Rolling Speed	0-40m/min( without the cutting time)
3.Main body	Roller Stations	About 14 stations
	Roller Material	45# Steel with quenching 60mm shaft
	Maim Motor Power	7.5 kw
	Hydraulic cutting Power	8.5 kw
	Bearing	Rubber sealing bearing
	Material Of Cutting	CR12 with quench treatment
	Hardness	HRB 85-95
	Tolerance	+-1.5mm
4.Cutter	Cutting way	Stop cutting
5.Voltage	Electric Source	380V 50Hz 3Phase Also can satisfy Customer’s require
6.Control system	Control System	PLC Delta
	Inverter	Yaskawa
	Weight	About 2.5 tons
	Way Of Drive	1 inch single chain
	MOTOR	Under the frame of the machine

More pictures of the machine：
